 XSG系列快速旋轉閃蒸干燥機
>> 技術參數：
型號 |
筒體直徑 |
主機尺寸 |
主機功率 |
處理風量(m3/h) |
蒸發水量(kg/h) |
| XSG-2 |
200 |
250×2800 |
5-9 |
300-800 |
10-20 |
| XSG-3 |
300 |
400×3300 |
8-15 |
600-1500 |
20-50 |
| XSG-4 |
400 |
500×3500 |
10-17.5 |
1250-2500 |
25-70 |
| XSG-5 |
500 |
600×4000 |
12-24 |
1500-4000 |
30-100 |
| XSG-6 |
600 |
700×4200 |
20-29 |
2500-5000 |
40-200 |
| XSG-8 |
800 |
900×4600 |
24-35 |
3000-8000 |
60-600 |
| XSG-10 |
1000 |
1100×5000 |
40-62 |
5000-12500 |
100-1000 |
| XSG-12 |
1200 |
1300×5200 |
50-89 |
10000-20000 |
150-1300 |
| XSG-14 |
1400 |
1500×5400 |
60-105 |
14000-27000 |
200-1600 |
| XSG-16 |
1600 |
1700×6000 |
70-135 |
18700-36000 |
250-2000 |
|
|
|
